Informații suplimentare
| Porturi LAN |
10/100 x 5 |
|---|---|
| Porturi SFP |
nu |
| Viteza de transfer |
10/100 Mbps |
| Management |
nu |
| Rackabil |
nu |
| Carcasa |
metalica |
Link producător:
https://www.tendacn.com/product/tef1105p-4-38w.html
| Network standards | IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、 IEEE 802.3af |
| LED Indicator | 5* Link/Ack LED indicators 1 * Power LED indicator |
| Interfaces | 4*10/100 Base-TX Ethernet Ports(Data/Power) 1*10/100 Base-TX Ethernet Port(Data) |
| Transmission media | Recommended: CAT5/5e UTP or better |
| Dimension | 100.0mmx100.0mmx26.0mm |
| Level of protection | Lightning protection for ports: 6kV Lightning protection for power: 6kV ESD: Air discharge: ±10kV Contact discharge: ±8kV |
| Forwarding mode | Store-and-forward |
| Switch capacity | 1Gbps |
| Packet forwarding rate | 0.74Mpps |
| Buffer | 448K |
| MAC address table | 1K |
| PoE budget | Single port: AF: 15.4W, AT: 30W Whole device: 35W |
| Power consumption | / |
| Input voltage | 100－240V AC 50/60Hz 48V /0.8A DC（Power Adapter Output） |
| Mounting | Desktop mounting: support Wall mounting: support Rack mounting:non-support |
| Environment | Operating Temperature: 0℃~45℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Certification | FCC、CE、RoHS |
| Funtions | Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other. Extend Mode: If Extend mode is enabled, Port 1-4 will be isolated respectively (10Mbps auto-negotiation).And the delivery distance of powering and network data is up to 250m (10Mbps). |
